Frame
frame

Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, Fully Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points
size

Size Split: 27.5: S (16") // 29: M (18"), L (20"), XL (22")
Suspension
Suspension fork

RockShox Recon Silver RL Air, Tapered, 15x110mm, eMTB Approved, 130mm, Lockout
shock

RockShox Deluxe Select, 185x55mm (27.5: 165x45mm), Rebound Adjust, Trunnion Mount
shock hardware

Top: 54mm Trunnion Mount, Bottom: 30x8mm
E-bike system
drive unit

Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
battery

Bosch PowerTube 625
Remote

Bosch LED Remote
charger

Bosch 4A
Drivetrain & brakes
brake system

Shimano BR-MT420, Hydr. Disc Brake (203/203)
rear derailleur

Shimano Deore RD-M6100-SGS, ShadowPlus, 12-Speed
shifters

Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
crankset

ACID E-Crank, 38T, 170mm
cassette

Sunrace CSMZ600, 11-51T
chain

Shimano CN-M6100
Cockpit
handlebar

Newmen Evolution SL 318.25, 760mm
Stem

CUBE Performance Stem E-MTB, 31.8mm
grips

ACID Hybrid Perform
headset

ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
Wheels
front hub

CUBE Engineered By Newmen, 15mm, Boost, Centerlock
rear hub

CUBE Engineered By Newmen, 12mm, Boost, Centerlock
rims

Rodi Tryp 30, 32H, Disc, Tubeless Ready
tyres

Schwalbe Smart Sam, Active, 2.6
Finishing kit
seat post

CUBE Performance Post, 30.9mm
saddle

Natural Fit Sequence
pedals

ACID PP MTB
Product information
weight

25,1 kg
colour

flashwhite´n´black
